Product Description
Mr.O
Tripod with built-in ball
Stability and fine control, a comfortable upgraded shooting experience
Mr.O's Spider is with a built-in hollow ball, which completely abandon the limitation of up-and-down straight center column and it can move and adjust the angle as freely as a ballhead. Mr.O series is a professional and powerful tripod which can support long lens and heavy cameras. With its low weight and versatile stability, Mr.O will become the new standard for outdoor tripods.
-20° to 40°
Low-temperature test of products. Lubricant in all Leofoto products is all Nichimoly brand made in Japan, which can make sure all the products can be used at -20° to 40° without any problem.
NSK / SUS304 / CU65%
Precise assembling and high-quality and durable parts. Leofoto bearings are NSK made in Japan and other parts are made of SUS304. All the parts are assembled by experienced technicians.
6061-T6
Leofoto's products are all made of international standard 6061-T6 aluminum alloy and its hardness is more than 18 degrees.
10X
Toray 100% 10-Layer Carbon Fiber
An excellent idea is easy to recognize.
We believe that our ideas can shape your passion. This is why Leofoto constantly strives to improve its own standards, inventing creative and functional solutions that turn ideas into reality. The numerous awards Leofoto products are granted each year bear witness to this innovation process. Design, functionality and technology are what makes our products special and universally recognized as the epitome of excellence in the photographic world.
- Model - LO-284C
- Diameter of tube - 28/25/22/19mm
- Max load - 12kg
- Weight - 1.32kg
- Leg section - 4
- Folded length - 480mm
- Height - 95~1540mm
We dare to think and dare to do
Mr.O's spider is with a built-in hollow ball, which completely abandon the limitation of up-and-down straight center column and it can move and adjust the angle as freely as a ballhead.
Every side is so eye-catching
Compact, light and incredibly elegant transcendent feeling on every part of the tripod.
Central control locking system
Four-axis high-speed precision sculpting craftmanship and 1mm spacing rectangular display processing central control locking system feature good hand feeling. Bold "Q shape" opening design Faster locking system which takes only half a turn.
1/4" mounting thread
Easy link to AM-1 & AM-2 magic arms for mounting cellphones and cameras,
3/8" mounting thread
Mounting holes on the apex of the tripod are perfect for magic arm or smarthphone clamp.
Ground Setting
Remove the center column by loosening the twist lock. Set the angle of the tripod to the maximum and install the included short center column, mounting platform and 3/8" to 1/4" mounting stud one by one, tighten the twist lock. Ground setting is now finished.
Center column can be reversed
Center column can be reversed for other shooting requests
Toray 100% 10-layer carbon fiber
Toray 100% 10-layer carbon fiber leg tubes feature cross rhombus structure for greater strength, stability and less vibration.
Anti-Twist System
On the center column, there are 2 allen screws (#1,2) to prevent the mounting base from twisting and 1 allen screw (#3) to prevent the ballhead from twisting.
Semi-automatic angle stop
Pull out the angle stop, raise the leg to your desired angle, slighly press the angle stop and it will ratchet into place and lock automatically. To reduce the angle stop automatic system, please pull out the angle stop completely and raise the leg to horizontal position until the angle stop engages.
Tripod Leg Twist Lock Mechanism
Quick lock/release with just 1/4 turns
Replaceable feet according to terrain.
Standard rubber feet protects indoor surfaces. Spiked feet is useful for softer ground like mud, gravel, sand or loose terrain.
When using at different angles / Reinforced aluminum alloy for the inner core
3/8" stainless steel screw threads allow replacement of different types of feet.
Single piece shim
Single piece shim is stronger, more reliable, and easier to maintain than 2 piece construction.
