Product Description
RØDELink represents the next generation of digital wireless systems. Using a series II 2.4GHz digital transmission with 128-bit encryption, it is able to constantly monitor and hop between frequencies to maintain the strongest possible signal level at a range of up to 100 metres* (over 100 yards). The RØDELink Filmmaker Kit provides everything you need to start shooting video wirelessly, including a receiver, transmitter and broadcast-grade lavalier microphone. The receiver (RX-CAM) features an OLED display with information on level, battery status (receiver and transmitter), mute and channel selection. The unit can be mounted on a standard camera shoe mount, 3/8" thread or belt-clip, and for added versatility the shoe mount can be located in one of two positions. The lightweight transmitter (TX-BELT) can be fitted to a belt or clothing and features a locking thread to ensure the microphone connection is as secure as possible. RØDE’s omnidirectional Lavalier microphone is included in the kit to provide the highest possible audio reproduction quality.
RØDELink Filmmaker Kit Specifications
- Transmission type: 2.4GHz Fixed Frequency Agile System
- System dynamic range: 112dB
- Range (distance): Up To 100m
- Frequency range: 35Hz - 22kHz
- Maximum output level: 1v Rms (2.8v P-p)
- Max input signal level: 1v Rms (2.8v P-p)
- Max latency: 4ms
Receiver (RX-CAM)
- Power source: 2 X AA Battery Or MicroUSB
- Antenna: Internal
- Output connection: 3.5mm TRS Locking Jack Socket - Dual Mono
- Output impedance: 300Ω
- Dimensions: 111mm X 65mm X 52mm
- Weight: 190gm
Transmitter (TX-BELT)
- Power source: 2 X AA Battery Or MicroUSB
- Antenna: Internal
- Output connection: 3.5mm TRS Locking Jack Socket
- Output impedance: 10kΩ
- Dimensions: 111mm X 65mm X 40mm
- Weight: 190gm
Lavalier
- Acoustic Principle: Pressure Gradient
- Active Electronics: JFET impedance converter
- Capsule: 0.10"
- Address Type: End
- Frequency Range: 60Hz - 18kHz
- Output Impedance: 3000Ω
- Maximum SPL: 110dB SPL (@ 1kHz, 1% THD into 1KΩ load)
- Maximum Output Level: 189.0dBu (@ 1kHz, 1% THD into 1KΩ load
- Sensitivity: -33.5dB re 1 Volt/Pascal (21.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
- Equivalent Noise Level (A-weighted): 25dB-A
- Weight: 1.00gm
- Dimensions: 12.00mmH x 4.50mmW x 4.50mmD
Condition: Brand new in original manufacturer's packaging
Contents: Transmitter, Receiver, Lavalier Microphone
